WEA7
发布时间：2021/02/01 WEA系列 浏览次数：3109
| 项目/Item WEA7 | 数值 Value | 单位 Unit |
| 输出转矩/Output Torque | 3.5 | kN.m |
| 倾覆力矩/Tilting Moment Torque | 14.2 | kN.m |
| 保持力矩/Holding Torque | 20 | kN.m |
| 轴向静载荷/Static Axial Rating | 220 | kN |
| 径向静载荷/Static Radial Rating | 90 | kN |
| 轴向动载荷/Dynamic Axial Rating | 63 | kN |
| 径向动载荷/Dynamic Radial Rating | 48 | kN |
| 减速比/Gear Ratio | 47:1 | — |
| 精度等级/Tracking Precision | ≤0.15 | ° |
| 重量/Weight | 35 | kg |
